Ingot capacity is the narrowest step in the solar chain – and the hardest to source. The CGS1000PV closes that gap with a puller engineered and supported from Europe.
Three numbers decide whether an ingot line makes money: the energy it takes to grow a kilogram of ingot material, the hours it runs each year, and the cost of keeping it running. The CGS1000PV addresses all three – with the hot zone. A larger process chamber leaves room for insulation that a 1,600 mm design cannot fit, so less heat escapes and less power is needed to replace it. A dual-zone heater shortens melt-down and limits oxygen uptake from the crucible. Long-lived heaters, in-situ servicing and hot turnaround between runs cut the downtime that follows every production cycle.
Technical Data
Specifications
| Crystal material | Silicon (Si) |
| Crystal diameter (max.) / Total crystal length (max.) | up to 305 mm (12“) / 7 m |
| Crystal weight (max.) / Si charge weight (max.) | 1,000 kg / 1,000 kg |
| Crucible size (standard) | 36“ (upgrade to 42“ possible) |
| Charge weight (standard) | for 36“ approx. 610 kg (500 kg initial charge + 110 kg recharged) (Optional with Feeding (3–5x) up to ~ 950 kg) |
| Melt temperature | approx. 1,420 °C |
| Melt-down time (500 kg Si) | approx. 6–7 hours |
| Max. side-heater power | 180 kW (both segments) |
| Max. bottom-heater power | 120 kW |
| Heating power during melt-down (500 kg) | approx. 250 kW |
| Heating power during crystal growth (300 mm) | approx. 50 kW |
| Process-chamber inner diameter | Ø 1,700 mm |
| Operating pressure (process) | 5–30 mbar |
| Leak rate | ≤ 3 × 10-² mbar·l/s |
| Argon gas flow | approx. 150 slpm |
| Main pump capacity | approx. 4,000 m³/h |
| Cooling water supply (inlet/outlet) | 20 / 50 °C |
| Fieldbus | PROFINET® and I/O-Link® |
Dimensions and Weight
| Footprint (complete system) | approx. 8 × 8 m |
| Overall dimensions (closed) | approx. 13,800 mm × 2,300 mm × 3,300 mm (h × w × d) |
| Overall dimensions (opened, highest lifting position) | approx. 14,600 mm × 5,500 mm × 5,000 mm (h × w × d) |
| Total system weight | approx. 20 to |
